Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles

Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles

  • Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles
  • Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles
  • Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles
  • Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles
  • Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles
  • Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles
Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles
Product Details:
Place of Origin: China
Brand Name: CIVL
Certification: ISO,CCC
Model Number: CIVL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: nude
Delivery Time: Within 35 days
Payment Terms: L/C, T/T
Supply Ability: 500units/month
Contact Now
Detailed Product Description
Axle: Fuwa Leg: Jost
Color: Option Tire: Triangle
Material: Q345 Condition: New
High Light:

tractor trailer trucks

,

flatbed Trailer Truck

Sinotruk cimc 40 ft van type container box semi truck trailer with rear door 4axles



40 foot container price for direct factory



shock price used container chassis





1.Load capacity:20 or 40''container


2.12 twist locks



3. Components: chassis,suspension,tyre and wheel,landing gear.



4. Payload: 20ton, 30ton,40ton,60ton,80ton.



5. Axle:2 axle or 3 axle or 4 axle



6. Certificate: ISO9001,2000; CCC



7. Guarantee: Our grantee term is 6 months. We will sent the engineer for mending the semi trailer for free within the six month.



8. Real low price with high quality





Usage And Method Of flatbed semi trailers



1.It is dedicated to all kinds of container transportation, can carry a 40 feet container, can also carry two 20 feet container at the same time, or a 20 ft container, customers can according to your own need to change the locks number. Beam using submerged arc welding, the trailer shot blasting derusting, pattern plate bottom is 3 mm thick, with non-slip design, all parts after 20 years of experience in using the selected supplier (can be found in ourweb site accessories suppliers, we can also according to the customer designated accessories suppliers purchasing abroad or in China.) , can be long-term repeated use, has the enough strength.



2.The flatbed semi trailer can according to customer requirements to equipped with removable panels and column etc.



3.Can undertake rapid loading and unloading, and can easily change directly from a means of transport to another transport.



4.We can according to the different requirements of customers to design the trailer ,or tell us t Tell us what you use. we will give you design the corresponding models, meet the personalized needs of customers



5.Design unique way of ocean transportation.

A. According to the customer the long-term destination, and customer location of welding process, the customer can choose bulk carrier(Three stacked, hanging off can be used directly after the goods to the port of destination.)





B container transportation.( Cutting back flat car, designed using the method of high strength screw connection .When receive the goods at the port of destination, with our first spare high strength screw connection, can carry 30 tons of goods directly, can also transport to the place where have welding ability to Put the screw welding smooth edges , the customer can be at ease use, this way in Kenya market has been in use for five years so far, no any abnormal situation happens







Detailed technical parameters of shock price used container chassis

flatbed tri axle trailer sale

Tare Weight About 7.1T
Dimension 12450mm*2490mm*1575mm
Loading Capacity (T) ≤ 45 T
Axle 13 T/16T, FUWA /BPW /Huajing Brand
Rim 9.00-22.5 or 9.75-22.5
Tire 12.00R22.5/ 315 80R22.5
Suspension

Mechanical suspension (Germany Type or America Type)

Or Air suspension (China brand or BPW brand )

Spring leaf

90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12

(especial for exporting market )

King pin JOST brand 2.0 or 3.5inch bolts type or Welding type
Support leg JOST brand D200T or China brand 28Tons (Double speed)
Main beam

Height: 500mm, upper plate is 14mm, middle plate is 8mm,

Down plate is 16mm; Material is Q345B Steel.

Side beam 16mm or 18mm channel steel (Material is Q235steel).
Bottom platform 3mm diamond steel plate
Brake chamber WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); one piece of 45L air tanks
ABS Optional
Twist Locks

Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type)

(especial for exporting market )

Valve WABCO valve (especial for exporting market )
Light LED light (especial for exporting market )
Voltage 24V
Receptacle 7 ways (7 wire harness)
Tool box One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms: By bulk cargo carrier, RORO or 40HQ container.

Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles 0Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles 1Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles 2Sinotruk Cimc 40 Ft Van Type Container Box Semi Trailer Trucks With Rear Door 4 Axles 3


Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts

Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
