Yellow 100 Ton All Terrain Crane XCMG QY100K-I Max. Travel Speed 80 Km / H

China Yellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / H supplier
Yellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / H supplier Yellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / H supplier Yellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / H supplier Yellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / H supplier

Large Image :  Yellow 100 Ton All Terrain Crane XCMG QY100K-I Max. Travel Speed 80 Km / H

Product Details:

Place of Origin: China
Brand Name: CIVL
Certification: ISO,CCC
Model Number: CIVL

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: nude
Delivery Time: Within 35 days
Payment Terms: L/C, T/T
Supply Ability: 500units/year
Contact Now
Detailed Product Description
Color: Yellow Condition: New
Engine: Cummins

100t all terrain crane XCMG QY100K-I truck crane

1. Main Technical Data Table in Travel configuration (Subject to improvement)



Category Item Unit Parameter
Outline Dimensions Overall length mm 15600
Overall width mm 3000
Overall height mm 3850
Wheel base mm 1420+2420+1800+1420+1505
Track mm 2610/2610/2610/2315/2315/2610
Front overhang mm 2550
Rear overhang mm 2225
Total vehicle mass in travel configuration kg 54900
Axle load 1st Axle kg 8000
2nd Axle kg 8000
3rd Axle kg 7900
4th Axle kg 12000
5th Axle kg 12000
6th Axle kg 7000
Power Superstructure engine Model   TAD720VE TAD750VE
Rated power kW/(r/min) 174/2300 181/2300
Rated torque N.m/(r/min) 854/1400 1050/1500
Carrier engine Model   OM460LA.E3A/1
Rated power kW/(r/min) 360/1800
Rated torque N.m/(r/min) 2200/1300
Travel Performance Max. travel speed km/h 80
Min. travel speed km/h 0.5
Min. turning diameter m 24
Min. turning diameter at boom tip m 26.6
Min. ground clearance mm 300
Approach angle ° 20
Departure angle ° 14
Braking distance (at 30 km/h ) m ≤10
Max. grade ability % 40
Oil consumption per 100km L 70
Noise Exterior noise level during acceleration traveling dB (A) ≤88
Noise level at seated position dB (A) ≤90


Yellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / HYellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / HYellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / HYellow 100 Ton All Terrain Crane XCMG QY100K-I  Max. Travel Speed 80 Km / H

Truck series:
1. Dump trucks; cargo trucks (1-120ton)
2. Tractor trucks; (1-120 tons)
3.Tanker trucks,( water tanker and oil tanker)
4. Mixer trucks and concrete pump truck
5. Mine dump trucks( 30 tons off-road mine tipper, 50tons/70tons mine dump truck, 6x6 articualted dump trucks)
6. Off-road drive trucks( 4x4. 6x6 and 8x8 Trucks)
7. Garbage trucks( garbage compactor truck, suction trucks)
8. Truck mounted cranes(normal road truck crane, truck mounted crane)
9. Special trucks( wrecker trucks, military trucks...)
10.Semi trailers( container semi-trailer, low-bed semi-trailer, tanker trailer, dumper trailer...)
11.Truck spare parts

Machine series:
1.Wheel loader,Backhoe loader
2.Roller
3.Motor Grader
4.Bulldozer
5.Excavator
6.Crane(truck crane,crawler crane,truck mounted crane,self erecting crane)
7.Forklift and 45t contain reach stacker
8.Paver and so on
9. Spare parts
