Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload

Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload

  • Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload
  • Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload
  • Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload
  • Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload
  • Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload
Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload
Product Details:
Place of Origin: China
Brand Name: CIVL
Certification: ISO,CCC
Model Number: CIVL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Nude
Delivery Time: Within 35 days
Payment Terms: T/T, L/C
Supply Ability: 100 units per week
Contact Now
Detailed Product Description
High Light:

Mini Wheel Loader

,

Compact Wheel Loaders



Promo Case Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload

Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload 0Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload 1



1.Description:



1.Heavy load for the rocky condition; the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity.

2.The large rock bucket with capacity of 3.0m³ is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of tooth holder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.

3.The thickness of the front frame lug and baseboard is 70mm, and the thickness of the up and down articulated board is 30mm. The machine is superior among the products of same kind in terms of the structural strength and carrying capacity.





2.Specifications:



Item

LW500KLParameter

Unit

Rated load

5000

kg

Tipping load

110

kN

Bucket capacity

3.0

m

Dumping height

3090

mm

Dumping distance

1130

mm

Lifting height

5262

mm

Bucket width

3000

mm

Max.drawing force


170

kN

Max. traction

175

kN

Articulation angle


±38

°

Dimension (Length × Width × Height )


8185×3000×3465

mm

Operating weight

17.4

t

Boom lifting time

≤6

s

Total time of three devices

≤11

s

Wheelbase

3300

mm

Tread

2250

mm

Min. turning radius(tyre center)

5925

mm

Min. turning radius (bucket outside)

6910

mm

Rated power/rotary speed

162/2200

kW/r/min

Engine model

WD10G220E23



Gradability

30

°

Speed

IGear (Forward/Backward)

11/13

km/h

II Gear (Forward)

36

km/h

Tyre specification

23.5-25-16PR





Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload 2Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload 3Wheel Loader LW500KL / 3 m³ , 3090mm Diesel 17.4t Payload 4

International Market:Ethiopia/Africa/Uganda/Chad/Zambia/Tanzania/Liberia/Myanmar

/Cambodia/Thailand/Malaysia



Other Truck can be provide according to your request, freely contact me for the informations and quotations.
