Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin

Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin

  • Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin
  • Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin
  • Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin
  • Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin
  • Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin
  • Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin
Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin
Product Details:
Place of Origin: China
Brand Name: CIVL
Certification: ISO,CCC
Model Number: CIVL
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negociable
Packaging Details: Waxed on deck or in container
Delivery Time: Within 35 days
Supply Ability: 1000 units/month
Contact Now
Detailed Product Description
Operating Weight: 10000KG Bucket Capacity: 1.8 M³
Dimension: 6905*2470*3028 Mm Fuek Box: 150L
High Light:

Small Wheel Loader

,

Compact Wheel Loaders

Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin



Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin 0Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin 1Strong Frame Small Wheel Loader Operating Weight 10T With FOPS Cabin 2

Advantage.



1. Strong frame, overloading capacity

2. High efficiency and low comsuption of fuel

3. Discharging heigth over 2700mm, satisfy your request.

4. This full hydraulic crawler excavator is all designed and produced by our company by adopting advanced technologies from Korea and Japan. With the features of low price, compact design, easy to operating, low noise, big power, it will be an ideal machine for you

5. Main parts such as main pump, swing motor, walking motor and multitandem valve are adopted international famous brand such as Doosan, Parker and so on, the quality and stable performance is highly increased.

6. Main structure parts are all produced by us, with advanced instruments; all the producing processes are under strictly controlled to make sure the quality of each part.

7. Swing speed is fast which increase the working efficiency

8. Wide space cab with air conditioner offers a comfortable working environment. Full digital monitor dynamically show the working condition of the machine.

Specifications

Basic Data

Bucket Capacity

1.8m³

Rated Load

3200kg

Travelling Speed

Forward 1st

0-12km/h

Forward 2nd

0-40km/h

Reverse 1st:

0-17km/h

Max.Traction

97kN

Max.Break Out Force

100kN

Min.Turn Radius (outside tyre)

5376mm

Max. Dumping Height

3060mm

Max. Reach

1008mm

Total Hydraulic Cycle Time

≤10.3s

Full Bucket Lifting Time

≤5.6s

Wheel Base

2750mm

Dimensions (LxWxH)

6970x2450x3286mm

Min. Clearance Over Ground

360mm

Operating Weight

10500kg

Diesel Engine

Model

Cummins 6BT5.9 or Yuchai YC6B125

Type

Direct injection, water cooling, 4 strokes

Rated Output

97/92kW

Rated Speed

2200rpm

Max. Torque

560N.m/460N.m

Transmission

Hydraulic Torque Converter Model

Single stage, two phase, four components

Transmission Type

2 forward and 1 reverse gears/hydraulic power shift,   planet type

Max. Permissible Temp.

120°C

Transaxle & Tyre

Drive System

4 wheel drive

Type of main Reducer

Spiral bevel gear, single stage

Type of hub Reducer

Planet gear

Tyre Size

17.5-25

Pressure Of Tyre

0.28-0.32MPa

Working Hydraulic System

Working Pump Type

Gear Pump

System Working Pressure

16MPa

Lifting Cylinder Bore x Stroke

125x816mm

Tilting Cylinder Bore x Stroke

140x553 mm

Steering System

Type

full hydraulic power steering system

Steering Pump Type

Gear Pump

Max. Working Pressure

10MPa

Steering Cylinder Bore x Stroke

80x380mm

Max. Steering Angle

±36º

Brake System

Type

Caliper disc brake, air over oil activate, 4 wheel   brake

Drive Brake System Pressure

0.71-0.784MPa

Parking Brake

Hand brake, drum type

Oil Injection Capacity

Fuel Tank

170L

Engine Oil

15L

Transmission

30L

Hydraulic Oil Tank

170L

Transaxle

30L



Photos







Other Truck can be provide according to your request, freely contact me for the informations and quotations.
