| Place of Origin: | China |
| Brand Name: | CIVL |
| Certification: | ISO,CCC |
| Model Number: | CIVL |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Waxed on deck or in container |
| Delivery Time: | Within 35 days |
| OperatingWeight: | 18T | Bucket Volume: | 3CBM |
|---|---|---|---|
| Dimension: | 8110×3000×3508mm | Engine Powe: | 220HP |
| Dumping Clearance: | 3090mm | Max.breakout Force: | 170Kn |
| High Light: | Mini Wheel Loader,Small Wheel Loader |
||
Powerful WEICHAI Engine
Hydraulic Transmission & Torque Converter
Pilot Control as Optional
Standard Air Condition
Variety with Attachment
Main Advantages :CE Certifications
1. The strong breakout force of 17 ton and strong traction of 17.5 ton ensure that the machine could adapt to various tough condition.
2. Reliable operation: with the long wheelbase of 3300mm and long machine body of 8185mm, the machine is ahead in the industry in terms of the operation reliability.
3. Quick action: the total time of three devices is only 10.3s, and the speed is 11.5 kmhour during the operation.
4. Strong adaptation to the work site: centered design, small turning raidus. No speed difference between front and rear wheels. The tyre is not easily worn.
5. The large rock bucket with capacity of 3.0CBM is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of toothholder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.
6. The thickness of the front frame lug and baseboard is 70mm, and the thickness of the up and down articulated board is 30mm. The machine is superior among the products of same kind in terms of the structural strength and carrying capacity.
| Bucket capacity | 3.0M³ |
| Rated load | 5000kg |
| Rated time | 6 secretary |
| Total cycling time | 11secretary |
| Max.drawing force | 145Kn |
| Max.breakout force | 170Kn |
| Articulation angle | 35. |
| Min.turn radius | 6400mm |
| Climb ability | 28. |
| Wheel base | 3300mm |
| Tread | 2200mm |
| Dumping clearance | 3090mm |
| Dumping reach | 1130mm |
| L×W×H | 8110×3000×3508mm |
| Operating weight | 18t |
Other Truck can be provide according to your request, freely contact me for the informations and quotations.
