Create more value and wealth through our quality products and professional solutions.
 |
| Place of Origin: | China |
| Brand Name: | SINOTRUK |
| Certification: | CCC/ISO |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | In container |
| Delivery Time: | Within 10 days |
| Payment Terms: | T/T |
| Supply Ability: | 1000 units/month |
| Name: | Roller Bearing | Model: | 190003326547 |
|---|---|---|---|
| High Light: | howo spare parts,heavy truck Parts |
||
| NO. | Part no | Part Name | Qty/Unit |
| - | AZ1246010049 | Cylinder block assembly | 1 |
| 1 | AZ1246010040 | Cylinder block | 1 |
| 2 | AZ1246010029 | Crankcase | 1 |
| 3 | VG1246010042 | Camshaft bush | 6 |
| 4 | VG1246010043 | Camshaft bush | 1 |
| 5 | 1.90004E+11 | Core hole plug | 9 |
| 6 | VG1246010044 | Core hole plug | 1 |
| 7 | VG1246010041 | Core hole plug | 2 |
| 8 | VG1246010046 | Core hole plug | 6 |
| 9 | VG1246010048 | Core hole plug | 2 |
| 10 | VG1246010032 | Positioning pin | 3 |
| 11 | VG1246010033 | Main bearing bolt | 14 |
| 12 | 1.90004E+11 | Core hole plug | 2 |
| 13 | 1.90004E+11 | Core hole plug | 1 |
| 14 | VG1540040011 | Screw plug | 1 |
| 15 | VG1246010093 | Stud | 14 |
| 16 | Q5211016 | Dowel pin | 12 |
| 17 | Q617B18 | Screw plug | 3 |
| 18 | VG9003080007 | Sealing washer | 3 |
| 19 | VG1246010129 | Socket plug | 1 |
| 20 | VG9003080003 | Sealing washer | 1 |
| 21 | VG1246010028 | Cylinder liner | 6 |
| 22 | VG1246010055 | Screw plug | 2 |
| 23 | VG1400010032 | O-ring | 1 |
| 24 | VG1246010031 | O-ring | 1 |
| 25 | Q150B08125 | Hex head bolt | 24 |
| 26 | Q41808 | Spring washer | 24 |
| 27 | VG1246010034 | Crankshaft main bearing(top) | 7 |
| 28 | VG1246010035 | Crankshaft main bearing(down) | 7 |
| 29 | VG1246010036 | Thrust washers | 2 |
| 30 | VG1246010039 | Oil injection nozzle assembly | 6 |
| 31 | Q5280308 | Spring dowel pin | 6 |
| 32 | 1.90004E+11 | Hollow bolt | 6 |
| 33 | VG9003080005 | Sealing washer | 6 |
| 34 | VG1246010001 | Front cover | 1 |
| 35 | Q5210820 | Dowel pin | 2 |
| 36 | Q1840835 | Hex head bolt | 7 |
| 37 | Q1840850 | Hex head bolt | 4 |
| 38 | VG1246010005 | Front crankshaft oil seal | 1 |
| 39 | VG9003813543 | Stud | 10 |
| 40 | Q1201045F3 | Stud | 2 |
| 41 | Q340B10 | Hexagon nut | 12 |
| 42 | Q40310 | Spring washer | 12 |
| 43 | AZ1246010019 | Flywheel housing | 1 |
| 44 | Q150B1240TF2 | Hexagon head bolts | 4 |
| 45 | Q150B12120TF2 | Hexagon head bolts | 11 |
| 46 | Q150B12105TF2 | Hexagon head bolts | 2 |
| 47 | VG1047010050 | Rear oil seal assembly (labyrinth type) | 1 |
| 48 | VG1800210011 | Observation hole cover | 1 |
| 49 | Q150B1018 | Hexagon head bolts | 2 |
| 50 | VG1246010022 | Front left bracket | 1 |
| 51 | Q5210814 | Cylindrical pin | 2 |
| 52 | VG1246010023 | Front right bracket | 1 |
| 53 | Q150B1475TF2 | Hexagon head bolts | 8 |
| 54 | Q40314 | Spring washer | 8 |
| 55 | Q40114 | Flat Washers | 8 |
| 56 | VG1246010025 | Flywheel shell transition plate | 1 |
| 57 | 5211232 | Cylindrical pin | 1 |
| 58 | Q5211222 | Cylindrical pin | 1 |
| 59 | Q150B1240TF2 | Hexagon head bolts | 4 |
| 60 | VG1246010085 | Engine oil filler pipe socket | 1 |
| 61 | Q1840845 | Hexagon flange bolts | 2 |
| 62 | Q1840890 | Hexagon flange bolts | 1 |
| 63 | VG1246010086 | Oil and gas separator components | 1 |
| 64 | VG1246010100 | Oil and gas separator gas hose | 1 |
| 65 | 1.90004E+11 | Hose clamp | 2 |
| 66 | Q150B0820 | Hexagon head bolts | 2 |
| 67 | Q40308 | Spring washer | 2 |
| 68 | Q40108 | Flat Washers | 2 |
| 69 | VG1246010101 | Oil-gas separator return hose | 1 |
| 70 | 1.90004E+11 | Hose clamp | 2 |
| 71 | VG1246010102 | Vent hose for oil and gas separator | 1 |
| 72 | 1.90004E+11 | Hose clamp | 1 |
| 73 | VG1246010096 | Oil return pipe joint assembly | 1 |
| 74 | VG2600010705 | Lower component of oil dipstick tube | 1 |
| 75 | Q617B18 | Hexagon head screw plug | 1 |
| 76 | VG1246070005 | Oil cooler cover | 1 |
| 77 | VG1246070006 | Safety valve | 1 |
| 78 | VG1246070007 | Safety valve spring | 1 |
| 79 | 1.90004E+11 | Light Hexagon Head Cylindrical Screw Plug | 1 |
| 80 | VG9003080012 | Composite sealing gasket | 1 |
| 81 | Q617B20 | Screw plug | 1 |
| 82 | VG9003080008 | Composite sealing gasket | 1 |
| 83 | VG1246070010 | Type 0 sealing ring | 2 |
| 84 | Q1840855 | Hexagon flange bolts | 7 |
| 85 | Q1840870 | Hexagon flange bolts | 4 |
| 86 | VG1246070028 | Support bolt | 1 |
| 87 | VG1246070080 | Support bolt | 1 |
| 88 | VG1246150001 | Dipstick assembly assembly | 1 |
| 89 | VG1246010131 | Sensor hole cover | 1 |
| 90 | Q150B0612 | Hexagon head bolts | 1 |
| 91 | Q41806 | Wave gasket | 1 |
Other Construction machinery can be provide according to your request, freely contact me for the informations and quotations.
DORIN (Ms)
1:mail : roadmachine@road-machine.com
2:Tel : 86+13210589366
3:Skype : 008613210589366
4:The company :SINO VEHICLE&EQUIPMENT COMPANY LTD
International Market:Ethiopia/Africa/Uganda/Chad/Zambia/Tanzania/Liberia/Myanmar
/Cambodia/Thailand/Malaysia
Contact Person: DORIN YANG
Tel: 008613210589366
